[TNT - Technical Data]

Technical Data Sheet - TNT Explosive

No.	Technical Specification	Range Requirements
1	Outer appearance:	Cast charges or flakes
2	Color:	Yellow (light yellow to dark yellow)
3	Solidification point,% not less than	80.2
4	Moisture and volatile substances, % not more than	0.1
5	Acidity as per sulfuric acid, % not more than	0.01
6	Insoluble matters in acetone (or benzene/ toluene) % not more than	0.05
7	Sodium, not more than %	0.001
8	Shelf life	min 20 years
TNT Flakes
9	Thickness of flake, average: max, mm	0.635
10	Thickness of flake max: max, mm	1.016
TNT cast charges (booster)
11	TNT weight per each cast charge (booster), g	400
12	Specific weight, g/cm³	1.35 ÷ 1.61
13	Average diameter, mm	90 ÷ 120
14	Average thickness, mm	30 ÷ 40

[C4-E - Technical Data]

C4-E Technical Data Sheet

No.	Description	Unit	Specification
1	Outer appearance:	-	Semi-cylindrical block of explosive, with a circular groove in the center, uniform in color ranging from white to yellow.
2	Dimension
3	Outer diameter of the explosive charge	mm	80 ± 2
4	Inner diameter of the explosive charge	mm	22 ± 1
5	Height of the explosive charge	mm	135 ± 3
6	Mass	g	500 ± 25
7	Moisture content and volatile substances, not more than	%	0.5
8	Density	g/cm³	1.45 ÷ 1.64
9	Plasticity [Needle penetration at 25°C, with density (1.10 ± 0.05) g/cm³]	mm	4.4 ÷ 9.5
10	Work potential using the pendulum impact method (compared to the explosive energy of TNT), not less than	%	116
11	Sensitivity by Cast method, not more than	%	52
13	Detonation velocity at density of (1.45 ± 0.01) g/cm³, not less than	m/s	7100
12	Lead column compression strength [weight (25 ± 0.01) g, at a density of (1.45 ± 0.01) g/cm³], not less than	mm	20
13	Thermal stability at 100°C for 40 hours, not more than	cm³/g	1.0

[RDX - Technical Data]

RDX Technical Data Sheet

No.	Technical Specification	Range Requirements
1	Outer appearance	Small crystalline form, odorless, with no impurities White, visible
2	Melting Point	Minimum 200 °C
3	Acidity (as HNO₃)	Maximum 0.05%
4	Insoluble Particles Remaining on U.S. Standard Sieve No. 60	Maximum 5 particles
5	Total Content of Insoluble Impurities in Marshall Defense	Maximum 0.05%
6	Total Content of Insoluble Inorganic Substances	Maximum 0.03%
7	Impact Sensitivity (Kast Method)	Maximum 84%
Particle Size Distribution: Standard Distribution
1	Passing through U.S. Standard Sieve No. 20	95–100%
2	Passing through U.S. Standard Sieve No. 50	70–100%
3	Passing through U.S. Standard Sieve No. 100	20–90%

[Comp B - Technical Data]

Comp B Explosive Technical Data Sheet

1. Technical specification of Hexolite explosive TNHH-TH40 particle and flake

No.	Criteria	Requirements
1	Outer appearance:	Solid, particle. Yellow/brown, no impurities visible to the unaided eye.
2	Ratio TNT/RDX/WAX, %	39,5 ± 2,3 / 59,5 ± 2,0 / 1,0 ± 0,3
3	Particle size
4	The passing rate through a 4 mesh sieve (hole 4.75 mm), %, not less than	98
5	The passing rate through a 40 mesh sieve (hole 0.0425 mm), %, not greater than	8
6	Melting temperature, °C	80 ± 1
7	Loose bulk density, g/cm³, not less than	0.9
8	Volatile substance content, %, not greater than	0.2
14	Ash content, %, not greater than	0.1
8	The work-generating capacity of the pendulum, compared to TNT, %, not less than	120
14	Detonation velocity (at a density of 1.65 g/cm³), m/s	8,500 ± 400

2. Technical specifications of Hexolite explosive TNHH-TH40 cast charge

No.	Criteria	Requirements
1	Outer appearance	Cylindrical explosive charge cast in a 0.5 mm thick paper tube. 1st type: 175 gram, Diameter Ø36 ± 1 mm 2nd type: 400 gram, Diameter Ø54 ± 1 mm
2	Ratio TNT/RDX/WAX, %	39,5 ± 2,3 / 59,5 ± 2,0 / 1,0 ± 0,3
3	Melting temperature, °C	80 ± 1
4	Volatile substance content, %, not greater than	0.2
5	Ash content, %, not greater than	0.1
6	The work-generating capacity of the pendulum, compared to TNT, %, not less than	120
7	Detonation velocity (at a density of 1.65 g/cm³), m/s	8,050 ± 400

[HMX - Technical Data]

HMX Technical Data Sheet

1. Appearance and dimension

No.	Technical Specification	Range Requirements
1	Outer appearance	Crystal, uniform small particles
2	Color	White
3	Particle size	The passing rate through a 48mesh sieve (48 holes/cm²) is 100%.

2. Physicochemical properties and technical explosive performance of HMX explosive

No.	Criteria	Unit	Requirement
1	Melting temperature	°C	≥ 270
2	Acidity (calculated as acetic acid)	%	≤ 0.05
3	Insoluble substances in acetone	%	≤ 0.05
4	Impact sensitivity	%	84 ÷ 96
5	Work capacity	% TNT	≥ 140
6	Detonation velocity (at a density of 1.25 g/cm³)	m/s	≥ 6,700
7	Moisture content (%)	%	≤ 0.1
